MED-X®

“MED-X®” has been designed for one purpose: to provide a high quality, transparent protective shield against X-Ray radiation. Its high lead and barium content gives optimum shielding against radiation from equipment in the 100 to 300 kV range. One of the leading products on the market, “MED-X®” has undergone extensive research and development - so you can trust its comprehensive protection in any medical, technical or research application.



Application Feature

Viewing windows and insulating glazing for X-Ray rooms.

  1. Screens for medical diagnostics.
  2. Protection windows in laboratories.
  3. Lenses for safety goggles.
  4. Airport security X-Ray screens.

High barium and lead content for optimum protection.

  1. Neutral appearance.
  2. Product of extensive research and development.
  3. World-class quality



Production Specification



MED-X®


  • "MED-X®” is supplied as polished plates and has maximum size of 1000 mm X 2000 mm
  • It is applicable for 2 standard thicknesses – 7 mm and 11 mm
  • Suitable for laminating using PVB interlayers when safety is required, and can be fitted into sealed double-glazing units.



Capabitity
Shielding Characteristics
Thickness Minimum lead equivalence (mm) for stated X-Ray tube Voltage Max.Plate Mass
mm inches 100KV 110KV 150KV 200KV 250KV

300KV

 kg/m2 lbs/ft2
7.0-8.5 0.276-0.335 2.3 2.3 2.1 1.8 1.8 1.8 40.8 8.4
11.0-13.0 0.433-0.512 3.6 3.6 3.3 2.8 2.7 2.8 62.4 12.8
