BR-LITE®

“BR-LITE®” is a bullet-resistant security glass composed of multi-layers of glass panes sandwich with layers of polyvinyl butyral.

BR-LITE® is designed for providing high levels of ballistic protection. Successive layers of glass and PVB interlayer serve to absorb the tremendous energy that needs to be dissipated when a bullet strikes the glass.





Application Feature
  • Drive-in banks and bank teller cages
  • Cashier booths and pay-out windows
  • Security screens
  • Glazing to VIP rooms
  • Military and armored vehicles
  • Prisons
  • Government buildings and Embassy
  • Jewelry store windows
  • Airports
  • Department stores Museum and hospitals
  • Post office and service station
  • Reduce the risk of death and injury by absorbing the bullet's energy and stop from breaching the final layer
  • High transparent and low distortion
  • Full range of ballistic protection
  • Glass thickness depends on the level of protection
  • Good sound insulation and UV protection



Production Specification



ITEM SIZE THICKNESS
Minimum (mm) Maximum (mm) Minimum (mm) Maximum (mm)
BR-LITE® 100 x 100 2000 x 3000 26 67



Capability



รุ่นผลิตภัณฑ์

BR-LITE®


  • Maximum Size : 2000 mm. x 3000 mm.
  • Maximum Weight : Not over than 400 Kgs./Unit.
  • 26mm for G0 classification (9mm Parabellum).34mm for G1 classification (.357 Magnum).
  • 49mm for G2 classification (.44 Magnum)53mm for R1 classification (5.56mm / M16)
  • 67mm for R2 classification (7.62mm / FAL NATO)
  • *** The frame for “BR-LITE” glass should be stronger and have deeper rebates than that for conventional glass. It must be capable of carrying additional mass of the glass while resisting high impact velocity.



Capability

There are 5 types BR-LITE® had pass the standard test of AS/NZS 2343:1997  BR-26, BR-34, BR-49, BR-53 and BR-67

PRODUCT TYPE    BR-LITE26 BR-LITE34 BR-LITE49 BR-LITE53 BR-LITE67
CLASSIFICATION G0 G1 G2 R1 R2
WEAPON 9 x 19 mm .357 Magnum .44 Magnum 5.56 x 45 mm M193 7.62 x 51 mm NATO
GLASS THICKNESS 26 mm ± 2 34 mm ± 2 49 mm ± 2 53 mm ± 2 67 mm ± 2
AMMUNITION 9 mm std. Full metal jacket bullet Soft point semi-jackted flat nose Soft point semi-jackted flat nose 5.56 full metal jacket bullet 7.62 mm NATO std. Full metal jecket
MASS (GRAM) 7.4 10.2 15.6 3.6 9.7
RANGE (METERS) 10 10 10 25 25
NO. OF STRIKES 3 3 3 3 3
STD. STRIKING VELOCITY (M/SEC) 4.05±15 4.05±15 4.80±15 9.80±1.5 8.5
