HEAT STOP®

“HEAT STOP®” is an energy saving glass that offers high visible light transmission, color neutrality, coating durability and superior performance in blocking heat transfer. “HEAT STOP®” effectively reflects heat back to its source, in summer, heat is absorbed by the glass and reflected back outside to lessen air-conditioning load. In winter during daytime, heat that is transmitted into the room is retained inside to lessen heating load.



Application Feature
  • "HEAT STOP®” can be used in any external application such as : Windows Curtain Wall or Facade.

“HEAT STOP®” offers the best (TECS) benefits in a single glazing :

  1. Transparency – the glass is clear or natural tint, which allows high light transmission into the room and reduces use of artificial lighting.
  2.  Energy saving – it reflects heat back outside in summer and back inside the room in winter to lessen cooling and heating load.
  3.  Comfort – because of low heat gain in summer and low heat loss in winter the room temperature remains ambient throughout the season.
  4. Safety – with laminated glass in one or both lites, when accidentally broken it does not shatter and remains integral in the frame.
Production Specification
HEAT STOP®



“HEAT STOP®” has a maximum size of 2440 mm X 3300 mm.
Available in cut sizes only and nominal thickness is 24 mm.



Capability

ITEM Optical performance Thermal Performance
Visible Rays Solar Energy U-value SC
Ref. In Ref.Out Trans Ref. Out Trans
3 MM. CLEAR 8 8 90 8 84 5.8 1.00
24 HEAT STOP® E-061 16 15 71 11 47 1.6 0.65
24 HEAT STOP® SE-0.61 15 10 53 8 33 1.6 0.49
24 HEAT STOP® SE-ARBL 15 7 38 5 20 1.6 0.34
24 HEAT STOP® E-ARBL 15 10 51 7 28 1.6 0.42
24 HEAT STOP® E-EGN 16 13 63 8 33 1.6 0.48
24 HEAT STOP® SE-EGN 15 9 47 6 24 1.6 0.38
